Multifunctional Two Head Terminal Machine For Single Wire Parallel Pressing

Fully automatic two-head terminal single-wire parallel pressing press crimper multi-functional five-line end machine cab

Machine Model KAR-SF005 appearance size 1380 * Width 750 * 1580 high (mm) machine weight 360Kg working voltage AC220V 50Hz working pressure 0.5 ~ 0.6 MPA (stable, clean, dry) rated power 1.8 kw machine function, wire cutting, double end peeling, single end half peeling, single-wire single-end pressing, single-wire double-end pressing, automatic terminal detection function cutting line length 26mm ~ 9999mm cutting line tolerance ≥1m, 0.5mm ~ 35mm (more than 12mm) of stripping length less than 0.02% cutting line speed 5500/h (less than 100mm) processing efficiency 4000 ~ 4800/h (less than 30 ~ 200mm) striking end pressure standard 2.0T, other pressure can be customized for wire AWG30 # ~ 14 # for OTP horizontal mold, straight mold (European mold can be customized) motors 5 sets of servo motors + 2 sets of Cycloidal manipulator step motor screw Rod 4 sets of TBI screw slide rail 7 sets of silver guide rail bearings, swedish SKF terminal holding capacity 2t/3t European precision frequency converter terminal machine

Multifunctional Two Head Terminal Machine

Single Wire Parallel Pressing Terminal Machine

Single Wire Parallel Pressing Terminal Equipment

Multifunctional Two Head Terminal Machine For Single Wire Parallel Pressing Images
